XRT/gauge: Dial and Gauge Widge
XRT/gauge includes 7 highly customizable dial and gauge widgets that measure the value of a property or attribute. Information is displayed in a format appropriate to the particular application environment. Motif developers can customize all aspects of information display, including style, color, range, numerical display, and much more. XRT/gauge widgets are ideal for environments with highly specialized requirements such as defense, manufacturing and aerospace. With XRT/gauge, Motif developers can quickly and easily create powerful interfaces that are not possible using conventional Motif sliders and scales
XRT/gauge can do much more than just display dials and gauges. With XRT/gauge user interaction routines Motif developers can easily build an application that lets end-users adjust a dial interactively, or manipulate orientation (horizontal, vertical) and direction (forward, backward).
With XRT/gauge, Motif developers can customize all aspects of the gauge display, including style, color, range, and much more. XRT/gauge widgets also feature customizable origin position, start & stop angle, and min & max values.
This Circular Gauge measures the value of a property or attribute and displays it using a needle.
The Circular Dial is a switch/knob that controls the value of a single property.
The Linear Dial is a linear scale/slider that controls the value of a single property with on/off regions.
The Linear Gauge measures the value of a property and displays it using a linear indicator.
The LED Icon displays an array of icons. The state of the LED icon (on/off) represents the state of a particular attribute.
The LED Numerical widget displays the value of a property or attribute in the form of LED numbers.
The Percent widget provides information about the state of a property or attribute in the form of a percentage or ratio.
